Drivelines & Spacers

Low Range Off Road is your source for Suzuki Samurai Driveline, or Drive Shaft Parts. We carry a huge inventory of hard to find parts and accessories.



FAQ:

Question: What does it mean for my Samurai if I have a "Small Flange" or a "Large Flange"?

Answer: If you have a 1986-1989 Samurai then you most likely have small flanges. This is usually indicated by a smaller 8mm diameter bolt.  Large Flanges years 1990-1995 have a larger 10MM bolt.

Question: If I have a Samurai that has a small flange, how do I run a Toyota Drive Shaft?

Answer: There are 2 ways to do this.

1. We recommend removing your front output flange from your transfer case first to see if the seal surface on the flange is still in good condition.  If the seal surface has grooves or has pitting from rust, we recommend that you replace your flange.  You can do this by purchasing a "Late Large Style Samurai Transfer Case flange" and notating in your order that you would like it machined to fit a Toyota Driveshaft Pilot Bore.  Please note that the Late Large Style Transfer Case flange will only work with Toyota Driveshafts that have a 60MM x 60MM bolt pattern.

2. The other way is running a Toyota Driveline Adapter such as the Pentadapter 5 Pattern Suzuki to Toyota Drive Line Adapter.  These are designed to be bolted directly to your Samurai 1986-1989 Small Pattern Flange on your transfer case and then bolted to a Toyota Driveshaft. These also give you many options in Toyota drivelines that can be used.  The only drawbacks to a driveline adapter is that they slightly increase the angle on your driveshaft. If you have an extreme amount of lift on a short wheelbase vehicle, the new late style flange may be best for you. They also increase the rotating mass of the drivetrain. Something that is almost laughable for the Samurai anyway because it is no racecar from the factory.


  1. Suzuki Samurai Driveline Boot

    Suzuki Samurai Driveline Boot

    $11.36
    Oil, the sun, old age... wrecks these poor things. Not too expensive to replace your old one and keep the splines on the driveline from getting messed up. Learn More


  2. Suzuki Samurai Late (Large) Transfer Case Rear Output Flange (Toyota Bolt Pattern)

    Suzuki Samurai Late (Large) Transfer Case Rear Output Flange (Toyota Bolt Pattern)

    Regular Price: $112.38

    Special Price: $97.95

    Want to put a Toyota driveline on your Samurai? You have two options. Either use a Toyota driveline adapter or run a larger flange that has a bolt pattern to match. This is the latter. Learn More


  3. Samurai OEM U-Joint

    Samurai OEM KOYO U-Joint

    $77.74
    These are factory original OEM Suzuki units. KOYO brand. They are non-greaseable which is partly the reason why they are so much stronger than aftermarket units. Learn More


  4. Suzuki Samurai OEM Style 1" Extended Drive Shafts with HD Ujoints Driveline, Front and Rear (SDT-D-F, SDT-D-R, SDT-D-F-9095, SDT-D-R-9095)

    Suzuki Samurai OEM Style 1" Extended Drive Shafts with HD Ujoints Driveline, Front and Rear (SDT-D-F, SDT-D-R, SDT-D-F-9095, SDT-D-R-9095)

    Starting at: $249.00

    If you need a new drive line or driveshaft and also an extended slip yoke or spacer then this may be your best option. These driveshafts are a step above OEM shafts as they are assembled with new components*.  The shaft itself has thicker than stock tubing, and pre-installed is new HD off road ujoints made with a multi-ton forging process.  We have yet to see one of these U-Joints break!

    Learn More


  5. Suzuki Samurai Transmission Crossmember Frame Notch Plate (For Driveline Clearance)

    Suzuki Samurai Transmission Crossmember Frame Notch Plate, For Driveline Clearance (STM-TMN)

    $29.00

    If you are lifting your Samurai more than the driveline will allow, the crossmember needs to be notched out- however, when the frame is notched, it looses it's frame stiffening strength and creates a void for what was there from the factory.

    Learn More


  6. 1990-1995 Suzuki Samurai Driveshaft Flange Yoke, Large Flange

    1990-1995 Suzuki Samurai Driveshaft Flange Yoke, Large Flange

    $77.95
    Low Range Off Road is your source for all Suzuki Samurai Drive Line and Drive Shaft Components and parts. We have new Prop Shaft or Drive Shaft Flange Yokes available for your Samurai. Fits: 1990-1995 Suzuki Samurai. Learn More


  7. Suzuki Samurai, Sidekick, X90 Geo Tracker Off Road Universal Joint

    Suzuki Samurai, Sidekick, X90 Geo Tracker Off Road Universal Joint

    $21.49
    Low Range Off Road over the years has searched high and dry for a Ujoint for Suzuki Samurai, Sidekick, Geo and Chevy Tracker, and X90 that could handle the loads that off roading puts on them. Now, finally, we have a ujoint that can meet our demands. What we now have available is a closed cell forged joint made on a 1100 Ton Multi-Ram Press. This is not your typical parts store ujoint. Learn More


  8. Suzuki Samurai Late (Large) Transfer Case Front Output/Input Flange (Toyota Bolt Pattern)

    Suzuki Samurai Late (Large) Transfer Case Front Output/Input Flange (Toyota Bolt Pattern)

    $89.00
    Want to put a Toyota driveline on your Samurai? You have two options. Either use a Toyota driveline adapter or run a larger flange that has a bolt pattern to match. This is the latter. Learn More


  9. Toyota PTFE Teflon Driveshaft Slip Yoke Lubricant Ford Motorcraft XG-8 (ML1167/31508-42027)

    PTFE Teflon Driveshaft Slip Yoke Lubricant Ford Motorcraft XG-8 (ML1167/31508-42027)

    $7.82

    When you are hitting the brakes on your Toyota Tacoma, Hilux, 4Runner or Sequoia and there almost seems like someone is hitting you in the rear it most likely is the cause of the drive line or drive shaft splines not lubricated.

    This is the best lubricant on the market for driveshaft slip yokes. It has a PTFE base, usually known as Teflon, most of which you see in heim joints or rod ends for great wear-ability. PTFE is also used in high friction applications because it does not easily get washed off when hit with water.

    Learn More


  10. Suzuki Samurai, Sidekick HD Standard U-Joint and CV Type Drivelines

    Suzuki Samurai, Sidekick HD Standard U-Joint and CV Type Drivelines

    Starting at: $339.00

    These drivelines are top quality and are heavy duty! They feature strong 1/2 ton 1310 u-joints and are available with double cardan CV joints to minimize driveline vibration with a range of motion up to 28 degrees. These shafts come ready built to match your rig with just about any lift you can run. Learn More


  11. Suzuki Samurai 1" and 2" Extended Slip Yokes

    Suzuki Samurai 1" and 2" Extended Slip Yokes

    Starting at: $85.00

    Extended slip yokes for Suzuki Samurai available in 1” or 2” longer than stock sizes. These can be used with the stock shaft portion of your driveline and do not cause an increase in u-joint operating angle as do the spacers. Made by Trail-Tough.

    Learn More


  12. Suzuki Drive Line, Driveshaft, Propshaft Spacers (1 1/4", 1.0", 3/4", and 1/2" Lengths)

    Suzuki Drive Line, Driveshaft, Propshaft Spacers (1 1/4", 1.0", 3/4", and 1/2" Lengths)

    Starting at: $24.50

    Adding lift to your Suzuki usually over extends the slip yokes on the drive shafts. The easiest and most cost effective fix is adding a drive shaft spacer. Doing so avoids the hassles of making a new drive shaft, which is not only difficult but expensive. The spacer works by attaching between drive shaft flanges.

    Learn More


  13. PENTADAPTER 5 Pattern Suzuki to Toyota Drive Line Adapters

    PENTADAPTER 5 Pattern Suzuki to Toyota Drive Line Adapters

    Starting at: $48.95

    5 Toyota Patterns and 1 Suzuki Pattern for adaptibility for your Suzuki Samurai, Jimny or Sierra to all Toyota Drivelines known to man.. except the 2007+ Toyota Tundra. It is a well known fact that Samurai drive lines weren’t the strongest ever built. Fortunately there is a great low cost alternative to custom made drive shafts. These spacers allow you to replace the stock pretzel you just bent with a much stronger Toyota drive line. They are also a good thing to have when you are doing the common Toyota axle swap. Learn More


  14. Steel Pinion Castor / Shims (pair) Samurai, Toyota, Jeep

    Steel Pinion Castor / Shims (pair) Samurai, Toyota, Jeep

    $45.95
    Caster angle has alot to do with many steering issues you may have. Most just worry about their pinion angle in the front but you have to deal with your caster angle first and pinion angle second. You generally between 2 and 5 degrees positive caster. That means the top of your tire is angled toward the fire wall. Kind of like a bycicle. For the rear you have to set your pinion angle differently for the type of drive shaft you are running. See the attached graphic. Learn More


  15. Samurai Bolt Pattern - Toyota Pinion Flange (100117-3-K)

    Samurai Bolt Pattern - Toyota Pinion Flange (100117-3-KIT)

    $29.00
    This Flange allows you to bolt your stock Samurai driveline to a Toyota differential without modifying the driveline.  Flange has both 1986-89 and 1990-95 Samurai driveline patterns. Learn More
